Transportation
Take a look at how Bogen can be integrated in various transportation spaces
You can find Bogen audio distribution systems in:
- Airports
- Bus stations
- Train terminals
- Parking garages
- Marinas
- Docks
- Wharves
- And many other transit locations.
Ticketing Area
1
8-ohm/70V/25V Drop-In Ceiling Speaker: CSD2X2U-V2
The Bogen CSD2X2U-V2 is a full-range ceiling speaker offering increased options for IP network designers and system integrators of Bogen Nyquist and other systems. The CSD2X2U-V2 can be converted into an intercom appliance, or a source amplifier/speaker for a secondary chain of 25V/70V speakers.
2
Nyquist VoIP Intercom Module: NQ-GA10PV (Connected to Monitor)
Bogen’s plenum-rated Nyquist VoIP intercom modules offer a convenient and cost-effective means of transforming any low-impedance analog speaker into a full-featured Power-over-Ethernet (PoE) IP speaker. The “PV” model adds HDMI video output for the visual messaging application found in Release 2.0 (and later releases) system software.
3
Nyquist VoIP Wall Baffle Combo Speaker w/LED Display & Flasher: NQ-S1810WBC
The Bogen Nyquist NQ-S1810WBC VoIP wall baffle combo speaker unit provides the same superior features as the NQ-S1810WT-G3 with the addition of a red LED messaging display and programmable flasher. There is no need for external amplifiers, traditional intercom wiring, or transformer taps to manually set or adjust. Connect the speakers via Cat5 to a PoE capable network switch (or add a PoE injector for a non-PoE switch), add the station into the system and it is ready to operate.
Baggage Claim
1
Nyquist VoIP Wall Baffle Combo Speaker w/LED Display & Flasher: NQ-S1810WBC
The Bogen Nyquist NQ-S1810WBC VoIP wall baffle combo speaker unit provides the same superior features as the NQ-S1810WT-G3 with the addition of a red LED messaging display and programmable flasher. There is no need for external amplifiers, traditional intercom wiring, or transformer taps to manually set or adjust. Connect the speakers via Cat5 to a PoE capable network switch (or add a PoE injector for a non-PoE switch), add the station into the system and it is ready to operate.
2
8-ohm/70V/25V Drop-In Ceiling Speaker: CSD2X2U-V2
The Bogen CSD2X2U-V2 is a full-range ceiling speaker offering increased options for IP network designers and system integrators of Bogen Nyquist and other systems. The CSD2X2U-V2 can be converted into an intercom appliance, or a source amplifier/speaker for a secondary chain of 25V/70V speakers.
Passenger Terminal(s)/Rail Platform(s)
1
Horn Loudspeakers: SPT15A
The SPT15A and SP158A are compact, high intelligibility, reentrant-type horn loudspeakers, designed for one-way or two-way sound and communication systems.
2
8-ohm/70V/25V Drop-In Ceiling Speaker: CSD2X2U-V2
The Bogen CSD2X2U-V2 is a full-range ceiling speaker offering increased options for IP network designers and system integrators of Bogen Nyquist and other systems. The CSD2X2U-V2 can be converted into an intercom appliance, or a source amplifier/speaker for a secondary chain of 25V/70V speakers.
Food Court
1
High Fidelity Ceiling Speaker: HFCS1
The Bogen HFCS1 ceiling loudspeaker delivers superior sound and clear intelligibility in a variety of ceiling environments. The system can be easily installed in hard-surfaced ceilings, suspended ceilings, and new constructions.
2
Nyquist VoIP Wall Baffle Combo Speaker w/LED Display & Flasher: NQ-S1810WBC
The Bogen Nyquist NQ-S1810WBC VoIP wall baffle combo speaker unit provides the same superior features as the NQ-S1810WT-G3 with the addition of a red LED messaging display and programmable flasher. There is no need for external amplifiers, traditional intercom wiring, or transformer taps to manually set or adjust. Connect the speakers via Cat5 to a PoE capable network switch (or add a PoE injector for a non-PoE switch), add the station into the system and it is ready to operate.
Outdoor Passenger Pick-up/Drop-off
1
A-Series All-Environment Loudspeaker: A2T (Connected to NQ-Amp)
Bogen’s A-Series A2T "Armadillo" loudspeaker features unique technologies that improve sound quality and operating reliability. Attractively styled, they are engineered for both indoor and outdoor applications.
Download the transportation guide!
Enter your info below & get immediate access
Transportation CAD Files and Bill of Materials Samples
Explore and download examples of CAD files and Bill-of-Materials (BOMs) tailored for the Transportation Industry. Need assistance with a design? Take a look at Bogen's Free Design Service.
Regardless of where your customers are headed, they need clear, accurate communications to get there swiftly and safely.
Provide commuters with boarding and schedule information, announce departures and arrivals, distribute general and emergency information, and integrate with access control and security systems. Discretely communicate with transportation employees using tone signaling to announce shift changes, breaks, emergencies, and more. In the event of an emergency, override paging and music with live Emergency All-Call or pre-recorded announcements, helping to provide quick response to critical conditions and send clear directives.
Nyquist C4000 IP-Based Paging and Intercom Solution
Case Studies
Challenge Must withstand salt air, rain, and wind Provide lifelike...
Challenge Update airport audio system with latest in technology and...
